ASK791.165 | Siemens Industry | Actuators & Dampers
ELECTRONIC FUSIBLE LINK, TEMP LIMIT 165F
Brand:Siemens Industry
MPN:ASK791.165
SKU:ASK791.165
product specifications
Accessory Type
Fusible Link
product series specifications
Input Impedance: 100kO @ 0/2-10VDC
GXA161.1P, GNP191.1P 100kO @ 0/2-10VDC
GXA151.1P 100kO @ 0/2-10VDC, 500O @ 4-20mA
Motor: Brushless DC
Life Expectancy: 60,000 cycles, 100,000 full stroke cycles, 7,000,000 repositions (GNP)
Rotation: 95°
Manual Override: Manual crank (except GQD), Disengage button (GNP)
Operating Temperature: -25° to 130°F (-32° to 55°C), 0° to 122°F (-18° to 50°C) (GNP)
Operating Humidity: 5 to 95% RH non-condensing
Motor: Brushless DC
Wiring: 3 ft (1.0 m), 18 AWG standard cable (.1U models), 3 ft (1.0 m), 18 AWG plenum cable (.1P models) See notes in Ordering Information for plenum option
Conduit Connections: 1/2" NPT (GCA, GMA only)
Resolution: 100 Steps
Noise: <40 db @ 3' (1m)
Input Impedance: 100kO @ 0/2-10VDC; 500O @ 4-20mA
Approvals: UL File #E35198, CE, plenum rated
Warranty: 2 years
product series features
- Self-centering shaft coupling
- Brushless DC motor technology
- Rugged, lightweight housings
more information & related documents
Series Description
The Siemens GMA and GCA Series direct-coupled spring-return actuators can control a complete range of HVAC spring-return damper applications. Each spring-return damper actuator is available in either 62 in-lb (7 Nm) torque, handling approximately 16 sq ft of damper area, or 160 in-lb (18 Nm) torque, handling approximately 40 sq ft of damper area. These damper actuators are available in all standard control signal types and offer a wide variety of options and accessories for building automation systems, BAS, applications.
Kele Description
ELECTRONIC FUSIBLE LINK, TEMP LIMIT 165F
Manufacturer
Siemens Industry
GCA Installation Instructions
